Bearing NO. | Type | Dimensions(in./mm) | Basic load ratings | Weight(kg) | ||||
d | D | C | B | dyc(Cr) | stc(Cor) | |||
W208 PPB2 | 1 | 1.5005 | 3.1496 | 0.709 | 1.6913 | 29500 | 18100 | 0.598 |
38.113 | 80 | 18 | 42.96 | |||||
W208 PPB7 | 1 | 1.18 | 3.1496 | 0.709 | 1.189 | 29500 | 18100 | 0.558 |
30.175 | 80 | 18 | 30.2 | |||||
W208 PPB10 | 3 | 1.5005 | 3.1496 | 0.8268 | 1.6913 | 29500 | 18100 | 0.817 |
38.113 | 80 | 21 | 42.96 | |||||
W208 PPB23 | 1 | 1.5005 | 3.1496 | 1.189 | 1.6913 | 29500 | 18100 | 0.817 |
38.113 | 80 | 30.2 | 42.96 | |||||
W209 PPB2 | 2 | 1.7717 | 3.3465 | 1.189 | 1.189 | 32700 | 20900 | 0.566 |
45 | 85 | 30.2 | 30.2 | |||||
W209 PPB4 | 2 | 1.535 | 3.3465 | 1.189 | 1.189 | 32700 | 23200 | 0.659 |
39 | 85 | 30.2 | 30.2 | |||||
W209 PPB11 | 1 | 1.7811 | 3.3465 | 0.866 | 1.437 | 32700 | 23200 | 0.573 |
45.24 | 85 | 22 | 36.5 | |||||
W210 PP2 | 4 | 1.938 | 3.5433 | 1.189 | 1.189 | 35000 | 23200 | 0.667 |
49.225 | 90 | 30.2 | 30.2 | |||||
W210 PPB2 | 2 | 1.939 | 3.5433 | 1.189 | 1.189 | 35000 | 23200 | 0.708 |
49.225 | 90 | 30.2 | 30.2 | |||||
W210 PPB5 | 2 | 1.785 | 3.5433 | 1.189 | 1.189 | 35000 | 23200 | 0.749 |
45.34 | 90 | 30.2 | 30.2 | |||||
W210 PP8 | 4 | 1.53 | 3.5433 | 1.189 | 1.189 | 35000 | 23200 | 0.836 |
38.862 | 90 | 30.2 | 30.2 | |||||
W211 PP2 | 4 | 2.18 | 3.937 | 1.311 | 1.311 | 43300 | 29200 | 1.01 |
55.575 | 100 | 33.3 | 33.3 | |||||
W211 PPB2 | 2 | 2.18 | 3.937 | 1.311 | 1.311 | 43300 | 29200 | 0.81 |
55.575 | 100 | 33.3 | 33.3 | |||||
W214 PP2 | 4 | 2.7559 | 4.9213 | 1.563 | 1.563 | 62100 | 44800 | 1.902 |
70 | 125 | 39.7 | 39.7 | |||||
W214 PPB2 | 2 | 2.7559 | 4.9213 | 1.563 | 1.563 | 62100 | 44800 | 1.667 |
70 | 125 | 39.7 | 39.7 | |||||
W214 PPB9 | 1 | 2.7661 | 4.9213 | 1.1024 | 1.75 | 62100 | 44800 | 1.902 |
70.26 | 125 | 28 | 44.45 | |||||
WIR210-31 | 5 | 1.937 | 2.543 | 0.787 | 1.937 | 35000 | 23200 | 0.74 |
49.2 | 90 | 20 | 49.2 | |||||
WIR211-33 | 5 | 2.063 | 3.937 | 0.827 | 2.189 | 43300 | 29200 | 1.122 |
52.388 | 100 | 21 | 56.6 | |||||
WIR212-39 | 5 | 2.437 | 4.331 | 0.866 | 2.437 | 47700 | 32800 | 1.249 |
61.912 | 110 | 22 | 61.9 |
